The Drone Gasoline Engine is an internal combustion engine specifically designed to power unmanned aerial vehicles (UAV) using gasoline (petrol) as fuel.
These engines are engineered to be lightweight yet powerful, providing the necessary thrust and endurance for extended flight missions.
They incorporate advanced technologies such as fuel injection systems, ignition controls,
and lightweight materials to optimize performance and efficiency while ensuring reliability in various operational conditions.
3Model Number 30CC 60CC 80CC 120CC 170CC 350CC
Product name Drone Gasoline Engine
Application Unmanned Aerial Vehicle / Drone
Weight 1.1kg 1.92kg 2.3kg 2.7kg 4.2kg 12.5kg
Power 8-18.5KW
Tension 7.5kg-80kg
Performance 3.7HP/8500rpm 7HP/8500rpm 8.5HP/8500rpm 12HP/7500rpm 17.5HP/7500rpm 20HP/7500rpm
Idle Speed 1100-2000 rpm/minute
Recommended Propeller 18*8 18*10 19*8 20*8 22*10 23*8 23*10 24*8 25*10 26*9 27*8 26*10 26*12 27*10 28*10 52*40 60*52
Spark Plug Type N G K CM6
Exhaust Amount/Displacement 30/60/80/120/170/350cm³
Diameter × Stroke 36mm*30mm 47mm*35mm 52mm*40mm 60mm*52mm
Compression Ratio 7.6:1 9.5:1 10.5:1
Lubrication Ratio 25:1 30:1
Ignition voltage 4.8V-14V
High-Performance Drone Gasoline Engine
Unlock the full potential of your UAV with our state-of-the-art Drone Gasoline Engine. Engineered for reliability, efficiency, and superior performance, this engine is crafted to meet the rigorous demands of modern unmanned aerial vehicles.
Key Features:
* Powerful Efficiency: Delivers exceptional power output while maintaining fuel efficiency,
extending your flight times significantly.
* Reliability: Built with robust materials and precision engineering to ensure consistent performance in challenging conditions.
* Compact Design: Optimized for weight reduction without compromising on durability, allowing for easier integration into various drone platforms.
* Advanced Technology: Incorporates cutting-edge fuel management systems and ignition control for enhanced operational control and safety.
Applications:
* Agriculture: Ideal for precision agriculture applications such as crop monitoring and spraying.
* Mapping and Surveying: Supports extended flight missions for mapping, surveying, and environmental monitoring.
* Security and Surveillance: Provides reliable power for extended surveillance missions in remote or inaccessible areas.
